Cross-Sliding Modules
Features
Sliding panel modules for the presentation of sample surfaces in sizes 100 x 200 cm or 120 x 240 cm. The systems are equipped with 10 side-sliding carrier frames. Additionally, two more sample surfaces of the same size can be displayed in the rear wall frame. The carrier frames move on ball-bearing rollers within a specially crafted base plate made from dyed material with a dark gray plastic coating. The sample boards or large-format tiles are secured along the entire height by an adjustable rail. The rail's clamping area is designed to fit samples with thicknesses ranging from 6 to 28 mm.
Assembly Details / Special Features
For secure stability, the system is designed to be mounted on a rear wall. The sample surfaces are displayed at a slight backward tilt. The floor area beneath the base plate should be level.
Cross-sliding systems for 12 sample surfaces consisting of 10 sliding panels + 2 wall frames.
Lateral Sliding Systems for 12 Samples Consisting of 10 Lateral Sliding Frames + 2 Wall Frames
Format: 100 x 200 cm
Livorno
Dimensions (WxDxH): 222 x 99 x 220 cm
Price (excl. VAT) 3.840,00 €
Add to RequestFormat: 120 x 240 cm
Venice
Dimensions (WxDxH): 262 x 99 x 260 cm
Price (excl. VAT) 4.395,00 €
Add to Request
